PXI-2568

The PXI‑2568 is a general-purpose switch module that features independent single‑pole single‑throw (SPST) Form A armature relays. Each relay is nonlatching with very low on-resistance and low thermal offsets. The PXI‑2568 is fully software programmable. With an efficient coupling of voltage/current capability and relay density, this switch module is ideal for automated test equipment (ATE) loads or for controlling heaters, lights, and fans.

Applications and Use Cases of PXI-2568

The PXI-2568 Relay Switch Matrix Module is a PXI-based relay switch matrix module designed for high-density signal routing, multiplexing, and automated switching systems. It provides flexible matrix configurations and reliable relay-based switching, making it ideal for automated test equipment (ATE), data acquisition systems, and large-scale measurement applications.

1. High-Density Matrix Signal Routing
PXI-2568 enables flexible routing between multiple instruments and DUTs through a configurable matrix architecture.

2. Automated Test Equipment (ATE)
Widely used in ATE systems for automatic switching of signal paths, test points, and measurement channels.

3. Multiplexed Measurement Systems
Allows multiple signals to share common instruments, reducing system cost and hardware complexity.

4. Multi-Channel Device Testing
Supports automated sequential or parallel testing of multiple DUTs and channels.

5. Industrial & Production Testing
Applied in manufacturing environments for automated electrical validation and high-throughput testing.

6. Data Acquisition & Instrument Sharing
Enables multiple sensors or devices to efficiently share DAQ and measurement resources.

7. Research & Laboratory Applications
Used in labs for flexible signal routing, configurable test setups, and instrumentation sharing.
