PXIe-6545
$24,800.00
Item details
Active Load: No
Number of Bidirectional Digital Channels: 32
Logic Levels And Range: 1.2 V, 1.5 V, 1.8 V, 2.5 V, 3.3 V
Supports Hardware Compare: No
Supports PMU: No
Signaling Type: Single-Ended
Maximum Generation Rate: 20 Mbits/s
Maximum Acquisition Rate: 20 Mbits/s
20
People watching this product now!
-
Warranty 1 year
-
Free 30-Day returns
付款方式：
NI PXIe-6545 Digital Waveform Instrument
20 MHz, 32-Channel PXI Digital Waveform Instrument
The PXIe‑6545 is a digital waveform generator and analyzer for interfacing with 32 single-ended digital pins. The device is capable of sampling digital waveforms at up to 20 MHz and interfacing with common transistor‑to‑transistor logic (TTL) voltage levels. The PXI‑6545 also features advanced synchronization capabilities for building integrated mixed-signal test systems and per-bank digital timing features.
Part Number(s): 780993-02 | 780993-03
Applications and Use Cases of PXIe-6545
The PXIe-6545 Digital Waveform Generator/Analyzer is a high-speed digital waveform generator and analyzer for PXI Express systems, designed for digital signal generation, acquisition, and high-speed interface testing.
| Application | Description |
|---|---|
| High-Speed Digital Waveform Generation & Acquisition | Generate and capture high-speed digital signals for waveform analysis |
| Digital Communication & Protocol Testing | Validate high-speed and custom digital interfaces |
| Semiconductor Testing | Test ICs, FPGAs, and memory devices using digital patterns |
| Embedded System & PCB Validation | Verify digital functionality of embedded systems and PCBs |
| Hardware-in-the-Loop (HIL) Simulation | Simulate and analyze digital signals in real time |
| Automated Test Equipment (ATE) | Integrate into automated production testing systems |
| Digital System Debugging | Analyze and debug high-speed digital systems |
